- Thin Mini-ITX
- Supports AMD AM5 Socket CPUs (Ryzen™ 9000, 8000 and 7000 Series Processors, up to 65W)
Supports Intel® CPU Cooler - Supports Dual DDR5 6400+(OC)MHz memory, Max. 96GB
- Multi Video Outputs: Dual HDMI, one DisplayPort, one LVDS
- Quad Storage Devices: Dual Hyper M.2 Socket (PCIe Gen4x4), Dual SATA 6Gb
- Abundant USB Ports:
1 x USB 3.2 Gen2 Type-C Ports,
1 x USB 3.2 Gen2 Type-A Port,
2 x USB 3.2 Gen1 Type-A Ports - Connector : (Optional) 1 x Onboard TPM 2.0 (INFINEON SLB9672 or NUVOTON NPCT750AADYX)
- 1 x Chassis Intrusion Header
- 1 x Panel Voltage Selection Header
- 1 x Backlight Inverter Voltage Selection Header
- 1 x FPD Brightness Header
- 1 x Panel Off Header
- 1 x LVDS Connector
- 1 x CPU Fan Connector (4-pin)
* The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.
- 1 x 4 pin 19V Power Connector
* (Optional) 1 x Chassis Fan Connector (4-pin) (Smart Fan Speed Control)
- 1 x Front Panel Audio Connector
- 1 x Internal Speaker Header (4-Pin)
- 1 x Digital MIC Header
- 2 x SATA Power Connectors
- 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection)
- 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)
Specifications
| CPU | Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors |
| Chipset | AMD X600 / Pro600 |
| Clearance - CPU Cooler | Supports CPU coolers with Intel® LGA1700 (78mm x 78mm) mounting holes |
| Memory | Dual Channel DDR5 Memory Technology , 2 x DDR5 SO-DIMM Slots, Supports DDR5 non-ECC, un-buffered memory up to 6400+(OC) ,Max. capacity of system memory: 96GB , Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules |
| BIOS | 256Mb AMI UEFI Legal BIOS with GUI support |
| Graphics | Integrated AMD RDNA™ graphics (Actual support may vary by CPU) |
| Audio | Realtek ALC269 Audio Codec, 1 x MIC IN ,1 x Line out |
| LAN | PCIE x1 Gigabit LAN 10/100/1000 Mb/s , Realtek RTL8111H |
| Slots | 1 x M.2 Socket (Key E), supports type 2230 Wi-Fi/BT PCIe Wi-Fi module |
| Rear Panel I/O | 1 x DC Jack (Compatible with the 19V power adapter) ,1 x DisplayPort 1.4 (DP2)* ,1 x HDMI Port: HDMI2 (Internal) ,1 x HDMI Port: HDMI1 (Rear)** , 1 x USB 3.2 Gen2 Type-A Port , 1 x USB 3.2 Gen2 Type-C Port*** , 2 x USB 3.2 Gen1 Type-A Ports , 1 x RJ-45 LAN Port with LED , HD Audio Jacks: Line out / Microphone |
| Unique Feature | ASRock Super Alloy ,High Density Glass Fabric PCB ASRock Full Spike Protection (for all USB, Audio, LAN Ports) |
| Form Factor | Thin Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm (Compatible with Mini-ITX) |
| Operating System | Microsoft® Windows® 10 64-bit / 11 64-bit |
| Warranty | 1 Year |
