- Provides cost-effective 802.11ac connectivity with speed up to 1.9Gbps
- Supports 3x3 Multiple-Input Multiple-Output (MIMO) technology with three spatial streams for maximum performance on both 2.4- and 5.0-GHz radios
- Dual Gigabit Ethernet LAN with Energy Efficient Ethernet and link aggregation support
- Secure guest WiFi access with 3rd party cloud managed guest WiFi services support
- Cisco Umbrella integration to protect wireless devices from malware and phishing
- Supported by the new Cisco® Find IT Network Management platform for easy management and control
- ingle Point Setup requires no controller, for easy, cost-effective deployment of multiple access points
- Works right out of the box with easy installation and mobile friendly web-based configuration and wizard
Specifications
| Standard | IEEE 802.11ac, 802.11a, 802.11n, 802.11g, 802.11b, 802.3af, 802.3u, 802.1X (security authentication), 802.1Q (VLAN), 802.1D (Spanning Tree), 802.11i (WPA2 security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460) |
| Ports | 2 LAN Gigabit Ethernet autosensing, 2- 10/100/1000 Ethernet, with support for 802.3at at PoE support is only for 1 port and not 2 ports |
| Cabling type | Category 5e or better |
| Antennas | Internal antennas optimized for installation on a wall or ceiling |
| Operating System | Linux |
| Buttons / Switch | Reset button |
| VLAN | 1 management VLAN plus 32 VLANs for SSIDs |
| Features | IEEE 802.11ac, 802.11a, 802.11n, 802.11g, 802.11b, 802.3af, 802.3u, 802.1X (security authentication), 802.1Q (VLAN), 802.1D (Spanning Tree), 802.11i (WPA2 security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460) |
| Layer 2 | 802.1Q-based VLANS, 32 active VLANS plus 1 management VLAN |
| Security | WPA, WPA2 |
| Secure management | HTTPS, SSID broadcast |
| Throughput | Up to 1.9Gbps data rate (real-world throughput will vary) |
| Recommended user support | Up to 200 connective users, 50 active users per radio |
| Number of access points per cluster | 16 |
| Active clients per cluster | 960 |
| Configuration | Web user interface |
| Management protocols | Web browser, Simple Network Management Protocol (SNMP) v3, Bonjour |
| Wireless Frequency Band | Dual concurrent radios (2.4 and 5 GHz) |
| Web firmware upgrade | Firmware upgradable through web browser, imported or exported configuration file |
| LED Indicator | One LED |
| Warranty | 1 Year |
