Standards and Protocols:
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
|
|
Interfaces:
• 24× 10/100/1000 Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) • 4× Gigabit SFP Slots
|
|
Network Media:
• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m) • 1000BASE-X: MMF, SMF
|
|
Fan Quantity:
2
|
|
Power Supply:
100-240V AC, 50/60Hz
|
|
PoE+ Ports(RJ45):
• Standard: 802.3at/af compliant • PoE+ Ports: 24 Ports • Power Supply: 250 W
|
|
PoE Ports (RJ45):
• Standard: 802.3at/af compliant • PoE+ Ports: 24 Ports • PoE Power Budget: 250 W*
|
|
Dimensions ( W x D x H ):
17.3 × 8.7 × 1.73 in (440 × 220 × 44 mm)
|
|
Mounting:
19" 1U rack mountable
|
|
Max Power Consumption :
• 32.1 W (with no power device connected) • 308.6 W (with 250W power device connected)
|
|
Max Heat Dissipation:
• 109.5 BTU/h (with no PD connected) • 1,052.9 BTU/h (with 250 W PD connected)
|
|
Switching Capacity:
56 Gbps
|
|
Bandwidth/Backplane:
56 Gbps
|
|
Packet Forwarding Rate:
41.7 Mpps
|
|
MAC Address Table Size :
8K
|
|
Packet Buffer Memory:
4.1 Mbit
|
|
Jumbo Frame:
9 KB
|
