| Phase |
Single Phase
|
| Form Factor |
Tower
|
| UPS Topology |
Online Double Conversion
|
| Energy Saving Technology |
Online ECO Mode Efficiency > 95%
|
| Features |
Active PFC Compatibility, Generator Compatibility, Start On Battery, EMI/RFI Filtration, LCD Panel, Emergency Power Off (EPO) Port
|
| Nominal Input Voltage ( Vac ) |
230 ± 10%
|
| Input Voltage Range |
160 ~ 300 (Vac)
|
| Adjustable Voltage Range |
0~50% Load for 110 ~ 300 Vac/ 0~60% Load for 120 ~ 300 Vac/ 0~80% Load for 140 ~ 300 Vac/ 0~100% Load for 160 ~ 300 Vac
|
| Input Frequency |
50 ± 10/ 60 ± 10(Hz)
|
| Input Frequency Detection |
Auto-sensing
|
| Rated Input Current ( A ) |
9
|
| Input Power Factor |
0.98
|
| Input Connector Type |
IEC C20
|
| Detachable Power Cord Plug Type |
Schuko x 1
|
| Power Cord Length |
5.9 ft/1.8 m
|
| Capacity |
2000 VA/1800 Watts
|
| On Battery Waveform |
Pure Sine Wave
|
| On Battery Voltage(s) |
208 ± 1%/ 220 ± 1%/ 230 ± 1%/ 240 ± 1%(Vac)
|
| Output Voltage/ Frequency Setting |
Configurable/Configurable
|
| On Battery Frequency |
50 ± 0.5%/ 60 ± 0.5%(Hz)
|
| ECO Mode Voltage Tolerance |
± 15 %
|
| overload protection |
Internal Current Limiting, Circuit Breaker, Fuse, 110~120% Load for 1 min, >120% Load Immediately(Line Mode),110~120% Load for 10 sec, >120% Load Immediately(Battery Mode),>130% Load Immediately(Bypass Mode)
|
| Crest Factor |
0.125694
|
| Harmonic Distortion |
THD＜3%(Linear Load),THD＜5%(Non-linear Load)
|
| Internal Bypass |
Automatic Bypass, Manual Bypass
|
| Outlet(s) |
Total 5
|
| Outlet Type: |
Hardwire Terminal Block x 1, IEC C13 x 4
|
| Outlet(s) - Battery & Surge Protected |
4
|
| Typical Transfer Time ( ms ) |
0
|
| Runtime |
15 min(Half Load),5 min (Full Load)
|
| Typical Recharge Time |
5 Hours
|
| maximum charge current |
1 A
|
| Battery Type |
Sealed Lead-acid
|
| Battery Quantity (Each RBP) |
6 pcs
|
| Battery Voltage (Each RBP) |
72 V
|
| Compatible Extended Battery Module |
BPSE72V45A
|
| Max.EBM Quantity |
3 pcs
|
| Surge Suppression ( Joules ) |
440
|
| Phone/Network Protection RJ11/RJ45 (Combo) |
1-in, 1-out
|
| LCD Information Display |
: Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information, Event & Log
|
| LCD Setting & Control |
Mode Setting, Alarm Setting, Input & Output, Battery Setting
|
| HID Compliant USB Port(s) |
1
|
| Audible Alarms |
Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault, Replace Battery
|
| Management Cable |
Power Cord x2, USB Cable x1, Phone Line x1(pcs)
|
| Power Management Software |
PowerPanel Business (Recommended)
|
| Enclosure Construction |
Metal
|
| Color |
Black
|
| Warranty |
1 Year Battery , 2 Years Parts , 3 Years Service
|
