| Phase |
Three Phase
|
| Form Factor |
Tower
|
| UPS Topology |
Online Double Conversion
|
| Energy Saving Technology |
Online ECO Mode Efficiency > 98%
|
| Normal Mode Efficiency |
0.95%
|
| Battery Mode Efficiency |
0.95%
|
| Features |
Active PFC Compatibility, Dual Power Inputs, Generator Compatibility, Maintenance Bypass, EMI/RFI Filtration, LCD Panel, LED Indicators, Emergency Power Off (EPO) Port
|
| Parallel Expansion |
4 (Max. Units)
|
| Nominal Input Voltage ( Vac ) |
Line to Neutral (L-N):220, 230, 240 Vac, Line to Line (L-L):380, 400, 415 Vac
|
| Input Voltage Range ( Vac ) |
Line to Neutral (L-N): 132 ~ 276 Vac Line to Line (L-L): 228 ~ 478 Vac
|
| Configurable Voltage Range |
Line to Neutral (L-N): 220 ~ 250 Vac Line to Line (L-L): 380 ~ 435 Vac
|
| Input Frequency |
50 ± 3/ 60 ± 3(Hz)
|
| Input frequency range |
40 ~ 70 (Hz)
|
| Rated Input Current ( A ) |
42
|
| THD |
<3% (Full Linear Load)
|
| Input Power Factor |
0.99
|
| Input Connector Type |
Hardwire Terminal Block
|
| Capacity |
30000 (VA)/27000 (Watts)
|
| On Battery Waveform |
Pure Sine Wave
|
| Output Voltage/ Frequency Setting |
Configurable/Configurable
|
| Rated Output Voltage |
Line to Neutral (L-N):220, 230, 240 Vac, Line to Line (L-L):380, 400, 415 Vac
|
| Output Voltage Tolerance |
1.5 %
|
| Output Frequency ( Hz ) |
50 ± 0.1/ 60 ± 0.1
|
| ECO Mode Voltage Tolerance |
± 10 %
|
| overload protection |
Internal Current Limiting, Circuit Breaker, Fuse, 105~110% Load for 60 min, 110~125% Load for 10 min, 125~150% Load for 1 min, >150% Load Immediately(Line Mode),105~110% Load for 60 min, 110~125% Load for 10 min, 125~150% Load for 1 min, >150% Load Immediately(Battery Mode), 125~130% Load for 10 min, 130~150% Load for 1 min, 150~400% Load for 1 sec, >400% Load Immediately(Bypass Mode)
|
| Crest Factor |
0.125694
|
| Harmonic Distortion |
THD＜1%(Linear Load),THD＜5.5%(Non-linear Load)
|
| Internal Bypass |
Automatic Bypass, Manual Bypass
|
| Outlet Type: |
Hardwire Terminal Block x 1
|
| Runtime |
9 min(Half Load),1 min(Full Load)
|
| Recharge Power |
Default 10 % (Selectable from 1~20% x UPS Capacity)
|
| Battery Type |
VRLA
|
| Battery Quantity (Each RBP) |
40 pcs
|
| Battery Voltage (Each RBP) |
240 V
|
| Single Battery Capacity |
12 V 12 AH
|
| LCD Information Display |
: Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information, Event & Log
|
| LCD Setting & Control |
Mode Setting, Input & Output, Battery Setting, Communication, Event & Log, Security Setting, Language
|
| Serial Port |
RS232 x 1 + RS485 x 1 + Dry Contact x1
|
| Audible Alarms |
Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault, Replace Battery
|
| Power Management Software |
PowerPanel Business (Recommended)
|
| Enclosure Construction |
Metal
|
| Color |
Black
|
| Ingress Protection |
IP20
|
| Warranty |
1 Year Battery , 2 Years Parts , 3 Years Service
|
