Number of Ports:
16 ports of 10/100/1000 Mbit / s, 4 SFP ports
|
|
Network Cables:
UTP category. 5, 5e (max. 100 m), EIA / TIA-568 100 ohm STP (max. 100 m)
|
|
Duplex Mode:
Full / half duplex speed for 10 / 100Mbit / s, Full duplex for Gigabit speed
|
|
Transmission Medium:
Interfaces with support MDI / MDI-X
|
|
Bandwidth:
40 Gbit/s
|
|
Transmission Method:
Store-and-forward
|
|
MAC Address Table Size :
16000 records
|
|
Max Speed Forwarding 64 bytes:
29.8 Mpps
|
|
Packet Buffer Size:
1 MB on the device
|
|
Power Input:
100-240 VAC, 50/60 Hz, internal universal power supply
|
|
Maximum Power:
14.06 W
|
|
Power Consumption:
6.7 W / 110 V, 7.2 W / 240
|
|
Certifications:
FCC Class A, CE Class A, ICES-003, VCCI Class A, C-Tick, BSMI
|
|
Security:
CUL, CE LVD
|
|
Warranty:
2 Years
|
|
Port Standards & Functions:
IEEE 802.3 10BASE-T Ethernet (copper twisted-pair), IEEE 802.3u 100BASE-TX Fast Ethernet (copper twisted-pair), IEEE 802.3ab 1000BASE-T Gigabit Ethernet (copper twisted-pair), Auto-ANSI / IEEE 802.3, IEEE 802.3x Flow Control
|
