Standards and Protocols:
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
|
|
Interfaces:
8 10/100/1000Mbps RJ45 Ports (Auto-Negotiation/Auto MDI/MDIX)
|
|
Network Media:
• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m)
|
|
Fan Quantity:
Fanless
|
|
Power Supply:
• 12 VDC/1 A External Adapter or • Obtain Power from PoE Source
|
|
Power Consumption:
6.4 W (220 V/50 Hz)
|
|
Dimensions ( W x D x H ):
8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm)
|
|
Bandwidth/Backplane:
16 Gbps
|
|
Packet Forwarding Rate:
11.9 Mpps
|
|
MAC Address Table Size :
8K
|
|
Packet Buffer Memory:
4.1 Mbit
|
|
Jumbo Frame:
9 KB
|
