Standards and Protocols:
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab , IEEE 802.3x
|
|
Interfaces:
24 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
|
|
Network Media:
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) 100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)
|
|
Fan Quantity:
Fanless
|
|
Power Supply:
100-240VAC, 50/60Hz
|
|
Power Consumption:
Maximum: 13.1W (220V/50Hz)
|
|
Dimensions:
11.6*7.1*1.7 in. (294*180*44 mm)
|
|
Mounting:
Rack Mountable
|
|
Maximum Heat Dissipation:
46.44BTU/h
|
|
Switching Capacity:
48 Gbps
|
|
Max. Packet Forwarding Rate:
35.712 Mpps
|
|
MAC Address Table Size :
8K
|
|
Functions:
• Isolation Mode: Ports 1-22 • Loop Prevention: Ports 1-24
|
|
Jumbo Frame Support:
10KB
|
|
Transfer Method:
Store and Forward
|
|
Certifications:
FCC, RoHS
|
