28-Port Gigabit Smart Managed Switch
Number of Ports: 24x 10/100/1000 Mbit/s, 4 SFP Ports |
Network Cables: UTP category. 5, 5e (max. 100 m), EIA / TIA-568 100 ohm STP (max. 100 m) |
Duplex Mode: Full / half duplex speed for 10 / 100Mbit / s, Full duplex for Gigabit speed |
Transmission Medium: Interfaces with support MDI / MDI-X |
Bandwidth: 58 Gbit/s |
Transmission Method: Store-and-forward |
MAC Address Table Size : 16000 records |
Maximum 64 Byte Packet Forwarding Rate: 41.7 Mpps |
Packet Buffer Size: 1 MB on the device |
Power Input: 100-240 VAC, 50/60 Hz, internal universal power supply |
Maximum Power Consumption: 16.81 W |
Power Consumption: 5.9 W / 110 V, 6.42 W / 240 |
Certifications: FCC Class A, CE Class A, ICES-003, VCCI Class A, C-Tick, BSMI |
Security: CUL, CE LVD |
Warranty: 2 Years |
Port Standards & Functions: IEEE 802.3 10BASE-T Ethernet (copper twisted-pair), IEEE 802.3u 100BASE-TX Fast Ethernet (copper twisted-pair), IEEE 802.3ab 1000BASE-T Gigabit Ethernet (copper twisted-pair), Auto-ANSI / IEEE 802.3, IEEE 802.3x Flow Control |
- 24 x 10/100/1000BASE-T ports
- 4 x Gigabit RJ45/SFP Combo ports
- Advanced L2 switching and security features
- L2+ Static Routing
- Optional “standard mode” or “surveillance mode” management user interface
